Product Details

Wireless Internet Modem - Category 12 - Quectel EM120K-GL (New Platform LTE-A)

New Platform version of the cat Quectel modem. This version supports all major US bands.

Top Speed:
Downlink: 600Mbps
Uplink: 150Mbps

Bands supported per major US cellular carrier**

AT&T: 2, 3, 4, 5, 6, 7, 8, 9, 12, 14, 17, 29, 30, 46, 66
Verizon: 1, 2, 3, 4, 5, 6, 7, 8, 9, 13, 46, 48, 66
T-mobile: 2, 4, 5, 6, 7, 8, 9, 12, 25, 26, 41, 46, 48, 66, 71

All Bands:

LTE-FDD: B1/2/3/4/5/7/8/12/13/14/ 17/18/19/20/25/26/28/292/30/321/ 66/71

LTE-TDD: 34/38/39/40/41/42/43/463 (LAA)/48 (CBRS)

Carrier Aggregation Support?
Yes: 3xCA

Cellular Antenna Ports:
2 (2x2 MIMO)

**Check for full cellular band support on the bands tab above.

NOTE: It is the customers sole responsibility to ensure that the cellular service is compatible with the above cellular modem. The Wireless Haven is not responsible, and will not rake returns, if the customer cannot find a cellular data plan to connect their modem to.
